CyberData 011146 Operation Manual page 39

On the SIP page, enter values for the parameters indicated in
Note
Web Page Item
SIP Settings
Enable SIP Operation
Register with a SIP Server
Buffer SIP Calls
Primary SIP Server
Primary SIP User ID
Primary SIP Auth ID
Primary SIP Auth Password
Re-registration Interval (in seconds)
Backup SIP Server 1
Backup SIP User ID
Backup SIP Auth ID
Backup SIP Auth Password
Re-registration Interval (in seconds)
Backup SIP Server 2
Backup SIP User ID
CyberData Corporation
The question mark icon (
after the Toggle Help button is pressed
Table 2-7. SIP Configuration Parameters
Description
When enabled, the device will transmit, receive, and process SIP messages according
to the configured SIP settings below.
When enabled, the device will attempt to register to the configured SIP Server(s) on
this page. To configure the device to send and receive point-to-point SIP calls, enable
SIP Operation and disable Register with a SIP Server (see
"Configure the Paging Groups (PGROUPS)
Also referred to as "delayed paging." Device will buffer up to four minutes of audio then
play back the recording after hang up or after the buffer is full.
Enter the SIP server address as an IPv4 address in dotted decimal notation or a fully
qualified domain name. This parameter also becomes the host portion of the SIP-URI
for the device's extension on the primary SIP server. This field can accept entries of up
to 255 characters in length.
Specify the SIP User ID for the Primary SIP Server. This parameter becomes the user
portion of the SIP-URI for the device's extension on the primary SIP server. Enter up
to 64 alphanumeric characters.
Specify the Authenticate ID for the Primary SIP Server. This parameter is required for
SIP registration authentication. Enter up to 64 alphanumeric characters.
Specify the Authenticate Password for the Primary SIP Server. This parameter is
required for SIP registration authentication. Enter up to 64 alphanumeric characters.
The SIP Re-registration interval (in seconds) is the SIP Registration lease time, also
known as the expiry. The supported range is 30-3600 seconds. Enter up to 4 digits.
Enter the backup SIP server address as an IPv4 address in dotted decimal notation or
a fully qualified domain name. This parameter also becomes the host portion of the
SIP-URI for the device's extension on the backup SIP server. This field can accept
entries of up to 255 characters in length.
Specify the SIP User ID for the first backup SIP Server. This parameter becomes the
user portion of the SIP-URI for the device's extension on the first backup SIP server.
Enter up to 64 alphanumeric characters.
Specify the Authenticate ID for the first backup SIP server. This parameter is required
for SIP registration authentication. Enter up to 64 alphanumeric characters.
Specify the Authenticate Password for the first backup SIP server. This parameter is
required for SIP registration authentication. Enter up to 64 alphanumeric characters.
The SIP Re-registration interval (in seconds) is the SIP Registration lease time, also
known as the expiry. The supported range is 30-3600 seconds. Enter up to 4 digits.
Enter a second backup SIP server address as an IPv4 address in dotted decimal
notation or a fully qualified domain name. This parameter also becomes the host
portion of the SIP-URI for the device's extension on the second backup SIP server.
This field can accept entries of up to 255 characters in length.
Specify the SIP User ID for the second backup SIP Server. This parameter becomes
the user portion of the SIP-URI for the device's extension on the second backup SIP
server. Enter up to 64 alphanumeric characters.
931803A
) in the following table shows which web page items will be defined
.
Parameters").
Setting Up the SIP Paging Server
Configure the SIP Parameters
Table 2-7.
Section 2.6.8,
Operations Guide
31
