Mounting
You have the option to use the following mounting template to mark, and then drill two 3/16" (0.1875") holes for the
mounting anchors.
To install and mount the Paging Server:
1. Install the mounting anchors in the holes, and position the Paging Server mounting holes over the anchors.
2. Use the two #6 sheet metal screws to secure the Paging Server onto the mounting surface.
Hole size for Anchor installation: 3/16" (0.1875")
Screws: #6 x 1-1/2" Screw
Contacting CyberData
Sales: (831) 373-2601 ext. 334
Corporate Headquarters
Support: 831-373-2601 ext. 333
CyberData Corporation
Web:
http://www.cyberdata.net/support/contactsupportvoip.html
3 Justin Court
RMA Dept: (831) 373-2601 ext. 136
Monterey, CA 93940, USA
Email: RMA@CyberData.net
RMA Status:
Phone: 831-373-2601
Fax: 831-373-4193
Warranty and RMA information is available at the following website:
www.CyberData.net
http://www.cyberdata.net/support/warranty/index.html
© 2011 CyberData Corporation ALL RIGHTS RESERVED
http://www.cyberdata.net/support/rmastatus.html
930131C
Quick Reference
Installation Quick Reference
PoE VoIP Paging Server
The IP Endpoint Company
Sip Compliant
010878
The VoIP Paging Server enables access to existing paging speakers through a VoIP phone system. This interface uses a
standard paging amplifier, and supports paging to multiple zones from a VoIP phone.
Product Specifications
Regulatory Compliance
FCC Class A, UL 60950, CE
Power Requirement
PoE or +48VDC
LAN Speed
10/100 Mbps
Protocol
SiP compliant
Part Number
010878
Dimensions
6.11"L x 4.05"W x 1.15" H
Weight
1.2 lbs.
Getting Started
Be sure that you have received all the parts described in the
●
●
Download the VoIP Paging Server Operations Guide at:
http://www.cyberdata.net/products/voip/digitalanalog/pagingserver/docs.html
Parts List
(1) VoIP Paging Server
(2) #6 Mounting Anchors
Quick Reference
Parts List
section.
(1) Mounting Template (see the last page)
(1) Mounting Kit
(2) #6 x 1 1/2" Screws
930131C
© 2011 CyberData Corporation ALL RIGHTS RESERVED
