CyberData 11146 Installation Quick Reference

Mounting

You have the option to use the following mounting template to mark, and then drill two 3/16" (0.1875") holes for the
mounting anchors.
To install and mount the V3 Paging Server:
1. Install the mounting anchors in the holes, and position the V3 Paging Server mounting holes over the anchors.
2. Use the two #6 sheet metal screws to secure the V3 Paging Server onto the mounting surface.
Drill Hole Size for Anchor Installation: 3/16" (0.1875")
Contacting CyberData
Sales: (831) 373-2601 ext. 334
Corporate Headquarters
Support: 831-373-2601 ext. 333
CyberData Corporation
Web: http://www.cyberdata.net/support/contactsupportvoip.html
3 Justin Court
RMA Dept: (831) 373-2601 ext. 136
Monterey, CA 93940, USA
Email: RMA@CyberData.net
RMA Status:
Phone: 831-373-2601
Fax: 831-373-4193
Warranty information is available at:
www.CyberData.net
Web: http://www.cyberdata.net/support/warranty/index.html
© 2011, CyberData Corporation, ALL RIGHTS RESERVED
http://www.cyberdata.net/support/rmastatus.html
930426D Quick Reference
Installation Quick Reference
VoIP V3 Paging Server
The IP Endpoint Company
SIP Compliant
011146
The VoIP V3 Paging Server enables access to existing analog paging systems through a VoIP phone system. This interface
supports standard amplifier connections and supports paging to multiple zones from a VoIP phone.
Parameter Factory Default
Setting
IP Addressing DHCP
a
IP Address 10.10.10.10
Web Access Username admin
Web Access Password admin
a
Subnet Mask 255.0.0.0
a
Default Gateway 10.0.0.1
a. Default if there is not a DHCP server present.

Getting Started

● Be sure that you have received all the parts described in the
Download the VoIP V3 Paging Server Operations Guide at the following website:
●
http://www.cyberdata.net/products/voip/digitalanalog/pagingserverv3/docs.html

Parts List

(1) VoIP V3 Paging Relay
(1) Mounting Kit
(2) #6 x1.25-inch, PanHead, Phillips Sheet Metal Screw
Quick Reference
Parts List section.
(1) Mounting Template (see the last page)
(2) Plastic Anchors
930426D © 2011, CyberData Corporation, ALL RIGHTS RESERVED
