1.3 Specifications

Specifications
Ethernet I/F
Protocol
Power Input
Line In:
Input Signal Amplitudes
Input Impedance
Line Out:
Output Signal Amplitudes
Output Level
Total Harmonic Distortion
Output Impedance
Page Port Output
Payload Types
Network Security
Operating Range
Storage Temperature
Storage Altitude
a
Dimensions
Weight
Boxed Weight
Compliance
Warranty
Part Number
a. Dimensions are measured from the perspective of the product being upright with the front of the product facing you.
CyberData Corporation
Table 1-1. Product Specifications
10/100 Mbps
SIP RFC 3261 Compatible
PoE 802.3af or 48VDC
2.0 VPP maximum
10k Ohm
2.0 VPP maximum
+2dBm nominal
0.5% maximum
10k Ohm
Balanced 600 Ohm 5VPP
G.711 a-law, G.711 µ-law, G.722, and G.729
TLS/SSL 1.2 and SRTP
o o
Temperature: -40 C to 55
Humidity: 5-95%, non-condensing
o o o
-40 C to 70 C (-40 F to 158
Up to 15,000 ft. (4573 m)
6.11 inches [155.19 mm] Length
4.05 inches [102.87 mm] Width
1.15 inches [29.21 mm] Height
1.2 lbs. [.54 kg]
1.8 lbs. [.82 kg]
CE; EMC Directive – Class A EN 55032 & EN 55024, LV Safety Directive –EN 60950-
1 and EN 62368-1, RoHS Compliant, FCC; Part 15 Class A, Industry Canada; ICES-
3 Class A, IEEE 802.3 Compliant
2 Years Limited
011146
931803A
o o
C (-40 F to 131 F)
o
F)
