CyberData 011146 Operation Manual page 32

2. On the Device page, you may enter values for the parameters indicated in
Note
Web Page Item
Line-in Settings
Enable Line-in to Line-out Loopback
Enable Line-in to Multicast
Multicast Address
Multicast Port
Detect Line-in Silence
Relay Settings
Activate Relay on Local Audio
Clock Settings
Enable NTP
NTP Server
Timezone
Current Time
Misc Settings
Device Name
Bypass DTMF
DTMF Duration
Beep on Init
Beep on Page
CyberData Corporation
The question mark icon (
after the Toggle Help button is pressed
Table 2-5. Device Configuration Parameters
Description
Line-in audio will play back out the device's audio output ports. This is the
lowest priority audio and will be preempted by any other audio stream.
Line-in audio will be sent to the specified multicast address and port. Playback
priority is determined by receiver(s)
Cannot be combined with Play Line-in Audio via Multicast (Fault Detection)
Address line-in audio will be sent to.
Port line-in audio will be sent to (1-65535).
If audio drops below a threshold on line-input, the fault line-in multicast stream
will be stopped to reduce network traffic.
The relay will be activated (closed) when the device is playing audio. Use this to
activate an external amplifier when the device is playing audio.
Sync device's local time with the specified NTP Server.
Use this field to set the address (in IPv4 dotted decimal notation or as a
canonical name) for the NTP Server. This field can accept canonical names of
up to 64 characters in length.
Enter the tz database string of your timezone.
Examples:
America/Los_Angeles
America/New_York
Europe/London
America/Toronto
See https://en.wikipedia.org/wiki/List_of_tz_database_time_zones
list of valid strings.
Displays the current time.
Type the device name. Enter up to 25 characters.
Bypassing DTMF will result in all calls being relayed to PGROUP 0 Any security
code entered for PGROUP 0 will be ignored if DTMF is bypassed
The duration, in milliseconds, of DTMF tones played out of the device's analog
audio ports (1-65535).
Device will play the user defined "pagetone" audio file when it boots.
Device will play the user defined "pagetone" audio file before playing a SIP
page.
931803A
) in the following table shows which web page items will be defined
.
Setting Up the SIP Paging Server
Configure the Device Parameters
Table 2-5.
for a full
Operations Guide
24
