2.3.4 Page Port Output Connections

Pin Description
Pin 1 Fault Sense Input (Common). See
Pin 2 Fault Sense Input (Sense). See
Pin 3 Positive 600-Ohm Audio Output
Output/Audio Ground
Pin 4 Negative 600-Ohm Audio Output.
Output/Audio Ground
Pin 5 Audio Ground Reference. See
Ground Reference".
Pin 6 Relay Contact - Common
Pin 7 Relay Contact - Normally Open
a. The 600-Ohm audio output of the page port is also suited for interfaces with lower input impedances.
b. 1 Amp at 30 VDC for continuous loads
2.3.4.1 Pin 1 and 2—Fault Sense Input (Common/Sense)
This input was designed as a method of monitoring an external amplifier that is equipped with a fault
sense relay.
When enabled via the web interface
this input (when closed) will play a user uploadable audio file out of the line-out connection and/or
place a SIP call to a pre-determined extension and play that file.
2.3.4.2 Pin 3, 4, and 5—Positive/Negative 600-Ohm Audio Output/Audio Ground
Reference
This output allows direct connection to paging amplifiers requiring a "Page Port" type input that
meets a balanced 600 Ohm 5VPP signal.
2.3.4.3 Pin 6 and 7—Relay Contact (Common/Normally Open)
When enabled on the web interface
an audio file is played out of the local line-out or 600 Ohm output, the relay will close, thereby
enabling amplifiers with a remote turn-on capability to become active.
CyberData Corporation
Table 2-1. Page Port Output Connections
Section 2.3.4.1, "Pin 1 and 2—Fault Sense Input
Section 2.3.4.1, "Pin 1 and 2—Fault Sense Input
a
. See Section 2.3.4.2, "Pin 3, 4, and 5—Positive/Negative 600-Ohm Audio
Reference".
a
. See Section 2.3.4.2, "Pin 3, 4, and 5—Positive/Negative 600-Ohm Audio
Reference".
Section 2.3.4.2, "Pin 3, 4, and 5—Positive/Negative 600-Ohm Audio Output/Audio
b
. See Section 2.3.4.3, "Pin 6 and 7—Relay Contact (Common/Normally
b
. See Section 2.3.4.3, "Pin 6 and 7—Relay Contact (Common/Normally
