1-2 Chapter 1: Module Overview
NOTE
Section 1.3
Input Types
and Ranges
NOTE
NOTE
User's Manual Pub. 0300247-01 Rev. D
Channel 0 through 3 can be configured for voltage or current and support
voltage and current ranges defined in Table 1-1. The module is shipped
with channels 6 and 7 in current mode (DIP switches inside unit both
down as shown below). The channel 1 switch below is associated with
module channel 6, and channel switch 2 is associated with module channel
7. Move each switch to the up position to achieve voltage input for each
respective channel. Refer to Figure 1-1 to view DIP switch location (item
10).
The table below lists the input types and their associated ranges.
Table 1-2 (Input Types)
Input Type
E Type Thermocouple
J Type Thermocouple
K Type Thermocouple -200 to 1370 ˚C (-328 to 2498 ˚F)
T Type Thermocouple
Voltage
Current
Channels 4 and 5 can be configured for current inputs only, and support
current input ranges as shown in Table 1-2.
Channels 6 and 7 can be configured for either current or voltage inputs.
Current support includes input ranges as shown in Table 1-2. Voltage
input ranges include both thermocouple and voltages as defined in Table
1-2.
Range
-200 to 1000 ˚C (-328 to 1832 ˚F)
-180 to 1200 ˚C (-292 to 2192 ˚F)
-190 to 400 ˚C (-310 to 752 ˚F)
0 to 5 V (0 to 5.5 V)
1 to 5 V (0 to 5.5 V)
±10 V (-11 to +11 V)
0 to 10 V (0 to 11 V)
4 to 20 mA (3.92 to 20.4 mA)
0 to 20 mA (0 to 20.4 mA)
