Spectrum Controls 1762sc-IF4OF4 User Manual page 35

1762 analog combo module 4 channels in/4 channels out
Table of Contents

Advertisement

Specification
Dimensions
Approximate Shipping Weight (with
carton)
Storage Temperature
Operating Temperature
Operating Humidity
Operating Altitude
Vibration
Shock
Bus Current Draw (max.)
Heat Dissipation
Resolution
Channel Update Time
Input Group to System Isolation
Module Power LED
5
The module update time is purely the sum of conversion times for each enabled channel. The extra
addition of 1 is not necessary.
User's Manual Pub. 0300247-01 Rev. D
Appendix A
Module Specifications
General Specifications
Value
90 mm (height) × 87 mm (depth) 40 mm (width)
Height including mounting tabs is 110 mm
3.54 in. (height) × 3.43 in. (depth) × 1.58 in. (width)
Height including mounting tabs is 4.33 in.
281 g (0.619 lbs.)
-40 °C to +85 °C (-40 °F to +185 °F)
-20 °C to +60 °C (-4 °F to +140 °F)
5% to 95% non-condensing
2000 meters (6561 feet)
Operating: 10 to 500 Hz, 5 G, 0.030 in. max. peak-to-peak
Operating: 30 G
30 mA at 5 VDC Max
3.4 W Max (140 mA max at 24 V)
3.0 W Total Max
16 bits (Integer Format)
Filter Setting
470 Hz
62 Hz
17 Hz
4 Hz
Channel to Rack: 707 VDC for 1 minute Optical and
magnetic Channel to Channel: Input channels are
differential as long as all pins are within 13 V dc of the
output return lines.
On: indicates power is applied and module not faulted.
Conversion
Module Update time
Time
20 ms
= Conversion time *
45 ms
(1+ number of
135 ms
enabled channels)
495 ms
5
