3-4 Chapter 3: Configuring the 1762sc-IF4OF4 for RSLogix 500
User's Manual Pub. 0300247-01 Rev. D
Table 3-1 (Output File)
Register Function
Output File (Used for Module Configuration)
O:e.0 Channel 0 Data Word
O:e.1 Channel 1 Data Word
O:e.2 Channel 2 Data Word
O:e.3 Channel 3 Data Word
O:e.4 Low byte: Channel 0 Configuration Register (Output)
High byte: Channel 1 Configuration Register (Output)
O:e.5 Low byte: Channel 2 Configuration Register (Output)
High byte: Channel 3 Configuration Register (Output)
O:e.6 Low byte: Channel 4 Configuration Register (Input)
High byte: Channel 5 Configuration Register (Input)
O:e.7 Low byte: Channel 6 Configuration Register (Input)
High byte: Channel 7 Configuration Register (Input)
1 2 3-4
See Table 3-2, See Table

3.4.2 Output Channel Configuration (Channels 0 through 3)

The table below describes the configuration options for analog output channels 0
through 3.
Table 3-2 (Configuration for Output Channels 0 through 3)
To Select
4 to 20 mA
0 to 20 mA
-10 to 10 V
0 to 10 V
Output Type
1 to 5 V
0 to 5 V
Reserved
Channel Disabled
Scaled for PID
Engineering Units
Data Format
Percent Range
Raw/Proportional Data
Unused
3
, See Table 3-5
Make these bit settings
7
0
1
1
1
1
2
2
3
3
6 5 4 3 2 1 0
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
0 0
0 1
1 0
1 1
0 0
