Chapter 3: Configuring the 1762sc-IF4OF4 for RSLogix 500
Table 3-6 lists the number of counts for each of the supported input channel data
ranges.
The engineering unit data formats represent real engineering temperature
NOTE
units provided by the module to the controller. The raw/proportional
counts, scaled-for-PID and percent of full-scale data formats may yield the
highest effective resolutions, but may also require that you convert
channel data to real engineering units in your control program.
Table 3-6 (Input Channel Data Ranges)
Input Range Input Value
J Thermocouple 1200.00 °C
1200.00 °C
-180.00 °C
-180.00 °C
K 1370.00 °C
Thermocouple
1370.00 °C
-200.00 °C
-200.00 °C
E Thermocouple 1000.00 °C
1000.00 °C
-200.00 °C
-200.00 °C
T Thermocouple 400.00 °C
400.00 °C
-190.00 °C
To Select
0 to 5 V
Type J TC
Type K TC
Type E TC
Type T TC
Type J TC CJC Disabled
Type K TC CJC Disabled
Type E TC CJC Disabled
Type T TC CJC Disabled
Display CJC channel temp
Channel Disabled
Condition EU ×1
High Limit 12000
High Range 12000
Low Range -1800
Low Limit -1800
High Limit 13700
High Range 13700
Low Range -2000
Low Limit -2000
High Limit 10000
High Range 10000
Low Range -2000
Low Limit -2000
High Limit 4000
High Range 4000
Low Range -1900
User's Manual Pub. 0300247-01 Rev. D
Make these bit settings
7 6 5 4 3 2 1
0 1 0 1
0 1 1 0
0 1 1 1
1 0 0 0
1 0 0 1
1 0 1 0
1 0 1 1
1 1 0 0
1 1 0 1
1 1 1 0
1 1 1 1
Raw
EU ×10
Prop
1200 32767
1200 32767
-180 -32768
-180 -32768
1370 32767
1370 32767
-200 -32768
-200 -32768
1000 32767
1000 32767
-200 -32768
-200 -32768
400 32767
400 32767
-190 -32768
3-7
0
PID
16383
16383
0
0
16383
16383
0
0
16383
16383
0
0
16383
16383
0
