Chapter 2: Installation and Wiring
Section 2.7
Module Indicators
User's Manual Pub. 0300247-01 Rev. D
Figure 2-7 (Door Label)
The 1762 combo module uses a single green LED to show operational status of
the module. The table below shows the possible blink codes.
Blink Code
Blinks rapid
The module is not in run mode.
green
Solid Green
Startup has completed, all internal tests have passed and the
module has received a valid configuration from the PLC.
Off
Hardware error.
Description
