A-2 Appendix A: Module Specifications
Specification
Recommended Cable
Specification
Vendor I.D.
Product Type
Product Code
Agency Certification
Hazardous Environment
Class
Radiated and
Conducted Emissions
Electrical /EMC:
ESD Immunity
(IEC61000-4-2)
Radiated Immunity
(IEC61000-4-3)
Fast Transient Burst
(IEC61000-4-4)
Surge Immunity
(IEC61000-4-5)
Conducted Immunity
(IEC61000-4-6)
6 Conducted Immunity frequency range may be 150 kHz to 30 MHz if the Radiated Immunity frequency
range is 30 MHz to 2700 MHz.
User's Manual Pub. 0300247-01 Rev. D
Value
Belden™ 8761 (shielded)
Value
58
10
22
C-UL listed (under CSA C22.2 No. 142)
UL 508 listed
CE compliant for all applicable directives
Class I, Division 2, Hazardous Location, Groups A, B, C,
D
(ISA 12.12.01, C-UL under CSA C22.2 No. 213)
Operating Temperature Code T4a
EN61131-2
The module has passed testing at the following levels:
4 kV contact, 8 kV air, 4 kV indirect
10 V/m, 80 to 1000 MHz, 80% amplitude modulation,
+900 MHz keyed
carrier
2 kV, 5 kHz
1 kV galvanic gun
6
10 V, 0.15 to 80 MHz
