Max_Input_Len
= 244
Max_Output_Len
= 0
;
; <Parameter-Definition-List>
;User_Prm_Data_Len = 4
;User_Prm_Data = 0x00,0x00,0x00,0x00
Max_User_Prm_Data_Len = 4
Ext_User_Prm_Data_Ref(3)=1
;
0123456789abcdef0123456789ABCDEF"
Module="voltage PH-N
L"
EndModule
Module="voltage PH-PH L"
EndModule
Module="apparent current L"
EndModule
Module="apparent power L"
EndModule
Module="active power L"
EndModule
Module="reactive power L"
EndModule
Module="cos phi"
EndModule
Module="lack of compensatory power"
EndModule
Module="actual target cos Phi"
EndModule
Module="switched stage power"
EndModule
Module="total stage power"
EndModule
Module="total apparent power"
EndModule
Module="total active power"
EndModule
Module="total reactive power"
EndModule
Module="frequency"
EndModule
Module="powerfactor"
EndModule
Module="THD voltage"
EndModule
Module="voltage 3.Harm"
EndModule
Module="voltage 5.Harm"
EndModule
Module="voltage 7.Harm"
EndModule
Module="voltage 9.Harm"
EndModule
Module="voltage 11.Harm"
EndModule
Module="voltage 13.Harm"
EndModule
Module="voltage 15.Harm"
EndModule
Module="voltage 17.Harm"
EndModule
Module="voltage 19.Harm"
EndModule
Module="distortion-current"
EndModule
Module="current 3.Harm"
EndModule
Module="current 5.Harm"
EndModule
Module="current 7.Harm"
EndModule
Module="current 9.Harm"
Version 1.0
MULTIGATE-Profibus / multisys 1D3-ESDP
;
;
Unit
0x41,0x83,
0
;
V
0x41,0x83,
1
;
V
0x41,0x83,
2
;
A
0x41,0x83,
3
;
VA
0x41,0x83,
4
;
W
0x41,0x83,
5
;
var
0x41,0x83,
6
;
-
0x41,0x83,
7
;
var
0x41,0x83,
8
;
-
0x41,0x83,
9
;
var
0x41,0x83, 10
;
var
0x41,0x83, 11
;
VA
0x41,0x83, 12
;
W
0x41,0x83, 13
;
var
0x41,0x83, 14
;
Hz
0x41,0x83, 15
;
-
0x41,0x83, 16
;
%
0x41,0x83, 17
;
%
0x41,0x83, 18
;
%
0x41,0x83, 19
;
%
0x41,0x83, 20
;
%
0x41,0x83, 21
;
%
0x41,0x83, 22
;
%
0x41,0x83, 23
;
%
0x41,0x83, 24
;
%
0x41,0x83, 25
;
%
0x41,0x83, 26
;
A
0x41,0x83, 27
;
A
0x41,0x83, 28
;
A
0x41,0x83, 29
;
A
0x41,0x83, 30
;
A
Format
Size
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
float
4
Page - 29 -
