; <Parameter-Definition-List>
;User_Prm_Data_Len = 4
;User_Prm_Data = 0x00,0x00,0x00,0x00
Max_User_Prm_Data_Len = 4
Ext_User_Prm_Data_Ref(3)=1
Module="device status (read and reset)"
EndModule
Module="clear-commands"
consumption
consumption
EndModule
; 0123456789abcdef0123456789ABCDEF"
Module="voltage PH-N L1-L3"
EndModule
Module="voltage PH-PH L1-L3"
EndModule
Module="current L1-L3"
EndModule
Module="current average. L1-L3"
EndModule
Module="apparent power L1-L3"
EndModule
Module="active power L1-L3"
EndModule
Module="reactive power (Q1) L1-L3"
EndModule
Module="reactive power (Qn) L1-L3"
EndModule
Module="cos Phi L1-L3"
EndModule
Module="powerfactor L1-L3"
EndModule
Module="max: voltage PH-N L1-L3"
EndModule
Module="max: voltage PH-PH L1-L3"
EndModule
Module="max: current L1-L3"
EndModule
Module="max: current average. L1-L3"
EndModule
Module="max: apparent power L1-L3"
EndModule
Module="max: active power L1-L3"
EndModule
Module="max: reactive power (Q1) L1-L3"
EndModule
Module="max: reactive power (Qn) L1-L3"
EndModule
Module="max: cos Phi L1-L3"
EndModule
Module="max: powerfactor L1-L3"
EndModule
Module="min: voltage PH-N L1-L3"
EndModule
Module="min: voltage PH-PH L1-L3"
EndModule
Module="min: current L1-L3"
EndModule
Module="min: current average. L1-L3"
EndModule
Module="min: apparent power L1-L3"
EndModule
Version 1.0
MULTIGATE-Profibus / multisys 1D3-ESDP
0x91,0xA0 ; reset status with <> 0 in Outputdata
0xA0 ; Bit0: reserved
; Bit1: reserved
; Bit2: reset endless active work counter
; Bit3: reset endless reactive work counter
; Bit4: reserved
; Bit5: reserved
; Bit6: reserved
; Bit7: reserved
Unit
0x41,0x8B, 1 ; V
0x41,0x8B, 2 ; V
0x41,0x8B, 3 ; A
0x41,0x8B, 4 ; A
0x41,0x8B, 5 ; kVA
0x41,0x8B, 6 ; kW
0x41,0x8B, 7 ; kvar
0x41,0x8B, 8 ; kvar
0x41,0x8B, 9 ; -
0x41,0x8B, 10 ; -
0x41,0x8B, 11 ; V
0x41,0x8B, 12 ; V
0x41,0x8B, 13 ; A
0x41,0x8B, 14 ; A
0x41,0x8B, 15 ; kVA
0x41,0x8B, 16 ; kW
0x41,0x8B, 17 ; kvar
0x41,0x8B, 18 ; kvar
0x41,0x8B, 19 ; -
0x41,0x8B, 20 ; -
0x41,0x8B, 21 ; V
0x41,0x8B, 22 ; V
0x41,0x8B, 23 ; A
0x41,0x8B, 24 ; A
0x41,0x8B, 25 ; kVA
Format Size
float 12
float 12
float 12
float 12
float 12
float 12
float 12
float 12
float 12
float 12
float 12
float 12
Float 12
float 12
float 12
float 12
float 12
float 12
float 12
float 12
float 12
float 12
Float 12
float 12
float 12
