KBR multisys 1D3-ESDP Operating Instructions, Technical Parameters page 21

Module name
max: current average. L1-L3 0x41,0x8B, 14 Maximum: current average L1
max: apparent power L1-L3
max: active power L1-L3
max: reactive power L1-L3
(Q1)
max: reactive power L1-L3
(Qn)
max: cos Phi L1-L3
max: power factor L1-L3
min: voltage PH-N L1-L3
min: voltage PH-PH L1-L3
min: current L1-L3
min: current average. L1-L3 0x41,0x8B, 24 Minimum: current average L1
min: apparent power L1-L3
min: active power L1-L3
min: reactive power L1-L3
(Q1)
min: reactive power L1-L3
(Qn)
Version 1.0
Config. Description
Maximum: current average L2
Maximum: current average L3
0x41,0x8B, 15 Maximum: apparent power L1
Maximum: apparent power L2
Maximum: apparent power L3
0x41,0x8B, 16 Maximum: active power L1
Maximum: active power L2
Maximum: active power L3
0x41,0x8B, 17 Maximum: 1st harm. reactive power L1 kvar
Maximum: reactive power L2
Maximum: reactive power L3
0x41,0x8B, 18 Maximum: Total reactive power L1
Maximum: Total reactive power L2
Maximum: Total reactive power L3
0x41,0x8B, 19 Maximum: cos Phi L1
Maximum: cos Phi L2
Maximum: cos Phi L3
0x41,0x8B, 20 Maximum: power factor L1
Maximum: power factor L2
Maximum: power factor L3
0x41,0x8B, 21 Minimum: voltage PH-N L1
Minimum: voltage PH-N L2
Minimum: voltage PH-N L3
0x41,0x8B, 22 Minimum: voltage PH-PH L1
Minimum: voltage PH-PH L2
Minimum: voltage PH-PH L3
0x41,0x8B, 23 Minimum: current L1
Minimum: current L2
Minimum: current L3
Minimum: current average L2
Minimum: current average L3
0x41,0x8B, 25 Minimum: apparent power L1
Minimum: apparent power L2
Minimum: apparent power L3
0x41,0x8B, 26 Minimum: active power L1
Minimum: active power L2
Minimum: active power L3
0x41,0x8B, 27 Minimum: 1st harm. reactive power L1
Minimum: reactive power L2
Minimum: reactive power L3
0x41,0x8B, 28 Minimum: Total reactive power L1
Minimum: Total reactive power L2
Minimum: Total reactive power L3
Table 11: Input data multimess 1F96-0-LED-ES-US1 (cont.)
MULTIGATE-Profibus / multisys 1D3-ESDP
Unit Format
A float
A float
A float
kVA float
kVA float
kVA float
kW float
kW float
kW float
float
kvar float
kvar float
kvar float
kvar float
kvar float
float
float
float
float
float
float
V float
V float
V float
V float
V float
V float
A float
A float
A float
A float
A float
A float
kVA float
kVA float
kVA float
kW float
kW float
kW float
kvar float
kvar float
kvar float
kvar float
kvar float
kvar float
