9
multicount basic LCD bus
9.1
GSD file for multicount basic LCD bus
;-----------------------------------------------------------------------------;
; GSD Multicount Energy Counter for PROFIBUS DP
; Fa. KBR GmbH, Am Kiefernschlag 7 , 91126 Schwabach
; Tel.: 09122/6373-0
; Date: 30.04.2004
;-----------------------------------------------------------------------------;
#Profibus_DP
; <Prm-Text-Def-List>
PrmText=1
Text(0)= "do not rotate float/REAL"
Text(1)= "rotate float/REAL"
EndPrmText
; <Ext-User-Prm-Data-Def-List>
ExtUserPrmData=1 "float/REAL byte rotation"
Bit(0) 0 0-1
Prm_Text_Ref=1
EndExtUserPrmData
;
GSD_Revision
= 2
Vendor_Name
= "KBR GmbH, Schwabach"
Model_Name
= "Multicount Basic"
Revision
= "1.0"
Ident_Number
= 0x08F8
Protocol_Ident
= 0
Station_Type
= 0
Hardware_Release
= "V1.0"
Software_Release
= "V1.00"
9.6_supp
= 1
19.2_supp
= 1
93.75_supp
= 1
187.5_supp
= 1
500_supp
= 1
1.5M_supp
= 1
3M_supp
= 1
6M_supp
= 1
12M_supp
= 1
MaxTsdr_9.6
= 60
MaxTsdr_19.2
= 60
MaxTsdr_93.75
= 60
MaxTsdr_187.5
= 60
MaxTsdr_500
= 100
MaxTsdr_1.5M
= 150
MaxTsdr_3M
= 250
MaxTsdr_6M
= 450
MaxTsdr_12M
= 800
Freeze_Mode_supp
= 0
Sync_Mode_supp
= 0
Auto_Baud_supp
= 1
Set_Slave_Add_supp
= 0
Min_Slave_Interval = 6
Modular_Station
= 1
Redundancy
= 0
Repeater_Ctrl_Sig
= 0
24V_Pins
= 0
Max_Diag_Data_Len
= 30
Max_Module
= 32
Slave_Family
= 0
Max_Data_Len
= 247
Max_Input_Len
= 244
Version 1.0
MULTIGATE-Profibus / multisys 1D3-ESDP
; company name
; device name
; device release
; Ident number
; PROFIBUS_DP Record
; slave station
;
;
; Baudrate 9.6kB supported
; Baudrate 19.2kB supported
; Baudrate 93.75kB supported
; Baudrate 187.5kB supported
; Baudrate 500kB supported
; Baudrate 1.5MB supported
; Baudrate 3MB supported
; Baudrate 6MB supported
; Baudrate 12 MB supported
; no Freeze Mode
; no Sync Mode
; automatic baudrate
; no addressing over BUS
; min. slave-poll-cycle
; modular concept
;
;
;
;
;
;
;
;
;
Page - 17 -
