8.2 Output data multimess 1F96-0-LED-ES-US1
2 modules exist with output data which can be used if required.
The status flags of the device can be read and deleted, various values such as extremes or meter counts can be
reset and certain switching operations can be performed.
Module name
device status (read and
reset)
clear-commands
The following table describes the meaning of the error flags.
Bit Meaning
0 Power outage has occurred
1 Reserved
2 Reserved
3 Reserved
4 Reset has been performed
5 Reserved
6 Reserved
7 Reserved
Bit Meaning
0 Rotating field error
1 Phase angle deviation
2 I-Dir (k and I of the current transformer were swapped)
3 Reserved
4 Reserved
5 Parameter error (default value replaces incorrect value)
6 Reserved
7 Reserved
Version 1.0
Configuration
0x91,0xA0
0xA0
Table 8: Output data multimess 1F96-0-LED-ES-US1
Table 9: Error status high byte multimess 1F96-0-LED-ES-US1
Table 10: Error status low byte multimess 1F96-0-LED-ES-US1
MULTIGATE-Profibus / multisys 1D3-ESDP
Description
Output data byte <> 0: Deleting status bytes
Input data 2 status bytes (see tables 3 and 4)
Output data byte:
Bit0: Reset of extreme values (only maxima)
Bit1: Reset of extreme values (only minima)
Bit2: Reset endless active energy counter HT/LT
consumption
Bit3: Reset endless reactive energy counter HT/LT
consumption
Bit4: Reset endless active energy counter HT/LT recovery
(only for Comfort devices)
Bit5: Reset endless reactive energy counter HT/LT
recovery (only for Comfort devices)
Bit 6 and 7: reserved
