MULTIGATE-Profibus / multisys 1D3-ESDP
9.2

Output data multicount basic LCD bus

3 modules exist with output data which can be used if required.
The status flags of the device can be read and deleted, various values such as extremes or meter counts can be
reset and certain switching operations can be performed.
Module name
device status (read and reset) 0x91,0xA0
clear-commands
switch-commands
The following table describes the meaning of the error flags.
Bit
0 Power outage has occurred
1 A limiting value has been violated
2 Reserved
3 External synchronous pulse is missing
4 Reset has been performed
5 Reserved
6 Reserved
7 Reserved
If the device is operated with an external synchronous pulse, BIT3 is set if the external synchronous pulse was
not available when a period value was saved.
In general, all global error-BITS set are reset by the master.
Bit
0 Rotating field error
1 Phase angle deviation
2 I-Dir (k and I of the current transformer were interchanged)
3 Set pulse length for the pulse output is not possible
4 Battery voltage critical
5 Parameter error (default value replaces incorrect value)
6 Reserved
7 Reserved
Page - 20 -
Configuration Description
Output data byte <> 0: Deleting status bytes
Input data 2 status bytes (see tables 3 and 4)
0xA0 Output data byte:
Bit0: Reserved
Bit1: Reserved
Bit2: Reset endless active energy counter HT/LT
consumption
Bit3: Reset endless reactive energy counter HT/LT
consumption
Bit4: Reset endless active energy counter HT/LT recovery
Bit5: Reset endless reactive energy counter HT/LT
recovery
Bit 6 and 7: reserved
0x20 Bit0: to high tariff (bit must change from 0 to 1)
Bit1: to low tariff (bit must change from 0 to 1)
Bits 2,3,4,5,6 and 7: reserved
Table 12: Output data multicount basic LCD bus
Table 13: Error status high byte multicount basic LCD bus
Table 14: Error status low byte multicount basic LCD bus
Meaning
Meaning
Version 1.0
