MULTIGATE-Profibus / multisys 1D3-ESDP
Max_Output_Len
= 3
;
; <Parameter-Definition-List>
;User_Prm_Data_Len = 4
;User_Prm_Data = 0x00,0x00,0x00,0x00
Max_User_Prm_Data_Len = 4
Ext_User_Prm_Data_Ref(3)=1
Module="device status (read and reset)"
EndModule
Module="clear-commands"
LT consumption
HT/LT consumption
LT supply
HT/LT supply
EndModule
Module="switch-commands"
EndModule
;
0123456789abcdef0123456789ABCDEF"
Module="voltage PH-N L1-L3"
EndModule
Module="voltage PH-PH L1-L3"
EndModule
Module="current L1-L3"
EndModule
Module="current average. L1-L3"
EndModule
Module="apparent power L1-L3"
EndModule
Module="active power L1-L3"
EndModule
Module="reactive power L1-L3"
EndModule
Module="cos Phi L1-L3"
EndModule
Module="total apparent power"
EndModule
Module="total active power"
EndModule
Module="total reactive power"
EndModule
Module="powerfactor"
EndModule
Module="time"
EndModule
Module="energyform synchronous pulse"
EndModule
Module="tariff index"
EndModule
Module="act.period value P consumption"
EndModule
Module="act.period value Q consumption"
EndModule
Module="act.period value P recovery"
EndModule
Module="act.period value Q recovery"
EndModule
Page - 18 -
;
0x91,0xA0
; reset status with <> 0 in Outputdata
0xA0
; Bit0: reserved
; Bit1: reserved
; Bit2: reset endless active work counter HT/
; Bit3: reset endless reactive work counter
; Bit4: reset endless active work counter HT/
; Bit5: reset endless reactive work counter
; Bit6: reserved
; Bit7: reserved
0x20
; Bit0: switch to HT (bit must go from 0 to 1)
; Bit1: switch to LT (bit must go from 0 to 1)
; Bit2: reserved
; Bit3: reserved
; Bit4: reserved
; Bit5: reserved
; Bit6: reserved
; Bit7: reserved
Unit
0x41,0x8B,
1
;
V
0x41,0x8B,
2
;
V
0x41,0x8B,
3
;
A
0x41,0x8B,
4
;
A
0x41,0x8B,
5
;
VA
0x41,0x8B,
6
;
W
0x41,0x8B,
7
;
var
0x41,0x8B,
8
;
-
0x41,0x83,
9
;
VA
0x41,0x83, 10
;
W
0x41,0x83, 11
;
var
0x41,0x83, 12
;
-
0x41,0x83, 13
;
-
0x41,0x83, 14
;
0x41,0x83, 15
;
-
0x41,0x83, 16
;
W
0x41,0x83, 17
;
var
0x41,0x83, 18
;
W
0x41,0x83, 19
;
var
Format
Size
float
12
float
12
float
12
float
12
float
12
float
12
float
12
float
12
float
4
float
4
float
4
float
4
unsigned long
4
-
unsigned long
4
unsigned long
4
float
4
float
4
float
4
float
4
Version 1.0
