Module name
error flags
Version 1.0
Config. Description
0x41,0x83, 39 error flags, defined as follows:
0x0001 no measurement voltage
0x0002 no main current
0x0004 no induced current
0x0008 excess voltage
0x0010 excess current
0x0020 harmonic wave error
0x0040 temperature too high
0x0080 thermostat switch off
0x0100 no steps programmed
0x0200 wrong user parameters
0x0400 wrong system parameters
0x0800 defective stage power
0x1000 unit too small
0x2000 overcompensation
0x4000 emergency shutdown
Table 16: input data BK12 (cont.)
MULTIGATE-Profibus / multisys 1D3-ESDP
Unit Format
unsigned
long
