MULTIGATE-Profibus / multisys 1D3-ESDP
8.3
Input data multimess 1F96-0-LED-ES-US1
The desired input data for the Profibus slave can be defined through any combination of the modules listed
below.
Module name
voltage PH-N L1-L3
voltage PH-PH L1-L3
current L1-L3
current average. L1-L3
apparent power L1-L3
active power L1-L3
reactive power L1-L3 (Q1)
reactive power L1-L3 (Qn)
cos Phi L1-L3
power factor L1-L3
max: voltage PH-N L1-L3
max: voltage PH-PH L1-L3
max: current L1-L3
Page - 14 -
Config.
Description
0x41,0x8B, 1
voltage PH-N L1
voltage PH-N L2
voltage PH-N L3
0x41,0x8B, 2
voltage PH-PH L1
voltage PH-PH L2
voltage PH-PH L3
0x41,0x8B, 3
current L1
current L2
current L3
0x41,0x8B, 4
current average L1
current average L2
current average L3
0x41,0x8B, 5
apparent power L1
apparent power L2
apparent power L3
0x41,0x8B, 6
active power L1
active power L2
active power L3
0x41,0x8B, 7
1st harm. offset reactive power L1
1st harm. offset reactive power L2
1st harm. offset reactive power L3
0x41,0x8B, 8
Total reactive power L1
Total reactive power L2
Total reactive power L3
0x41,0x8B, 9
cos Phi L1
cos Phi L2
cos Phi L3
0x41,0x8B, 10 power factor L1
power factor L2
power factor L3
0x41,0x8B, 11 Maximum: voltage PH-N L1
Maximum: voltage PH-N L2
Maximum: voltage PH-N L3
0x41,0x8B, 12 Maximum: voltage PH-PH L1
Maximum: voltage PH-PH L2
Maximum: voltage PH-PH L3
0x41,0x8B, 13 Maximum: current L1
Maximum: current L2
Maximum: current L3
Table 11: Input data multimess 1F96-0-LED-ES-US1
Unit
Format
V
float
V
float
V
float
V
float
V
float
V
float
A
float
A
float
A
float
A
float
A
float
A
float
kVA
float
kVA
float
kVA
float
kW
float
kW
float
kW
float
kvar
float
kvar
float
kvar
float
kvar
float
kvar
float
kvar
float
float
float
float
float
float
float
V
float
V
float
V
float
V
float
V
float
V
float
A
float
A
float
A
float
Version 1.0
