MULTIGATE-Profibus / multisys 1D3-ESDP
Module name
min: cos Phi L1-L3
min: power factor L1-L3
total apparent power
total active power
total reactive power (Q1)
zero conductor current
average zero conductor
current
frequency
power factor
cum. 15 min active power
total reactive power (Qn)
max: total apparent power
max: total active power
max: total reactive power
(Q1)
max: zero conductor current 0x41,0x83, 43
max: avg zero conductor
current
max: frequency
max: power factor
max:cum. 15 min active
power
max:total reactive power
(Qn)
min: total apparent power
min: total active power
min: total reactive power
(Q1)
min: zero conductor current
min: avg zero conductor
current
min: frequency
min: power factor
min:total reactive power (Qn) 0x41,0x83, 56
error status
active work consumption
reactive work consumption
Page - 16 -
Config. Description
0x41,0x8B, 29 Minimum: cos Phi L1
Minimum: cos Phi L2
Minimum: cos Phi L3
0x41,0x8B, 30 Minimum: power factor L1
Minimum: power factor L2
Minimum: power factor L3
0x41,0x83, 31 total apparent power
0x41,0x83, 32 total active power
0x41,0x83, 33 total reactive power
0x41,0x83, 34 zero conductor current
0x41,0x83, 35 average zero conductor current
0x41,0x83, 36 Power frequency
0x41,0x83, 37 Power factor
0x41,0x83, 38 15 min cumulated active power
0x41,0x83, 39 total reactive power
0x41,0x83, 40 Maximum: total apparent power
0x41,0x83, 41 Maximum: total active power
0x41,0x83, 42 Maximum: total reactive power
Maximum: zero conductor current
0x41,0x83, 44 Maximum: average zero conductor
current
0x41,0x83, 45 Maximum: Power frequency
0x41,0x83, 46 Maximum: Power factor
0x41,0x83, 47 Maximum: 15 min cumulated active
power
0x41,0x83, 48 Maximum: total reactive power
0x41,0x83, 49 Minimum: total apparent power
0x41,0x83, 50 Minimum: total active power
0x41,0x83, 51 Minimum: total reactive power
0x41,0x83, 52 Minimum: zero conductor current
0x41,0x83, 53 Minimum: average zero conductor
current
0x41,0x83, 54 Minimum: Power frequency
0x41,0x83, 55 Minimum: Power factor
Minimum: total reactive power
0x41,0x83, 57 error status
0x41,0x87, 58 active energy count (consumption)
0x41,0x87, 59 reactive energy count (consumption)
Table 11: Input data multimess 1F96-0-LED-ES-US1 (cont.)
Unit Format
float
float
float
float
float
float
kVA float
kW float
kvar float
A float
A float
Hz float
float
kW float
kvar float
kVA float
kW float
kvar float
A float
A float
Hz float
float
kW float
kvar float
kVA float
kW float
kvar float
A float
A float
Hz float
float
kvar float
unsigned
long
Wh float
varh float
