Bacharach Neutronics Mini-ICS Operation Manual page 52

Jumper
access port
in analyzer
Case
Figure 11 – Range select jumpers
0
0
1
Figure 12 – Range select jumper settings
Manual Part Number:
5-06-4900-53-0
Model Mini-ICS Bottom View
Ntron
Process Analyzer Division
Division of Neutronics Inc.
456 Creamery Way Exton, PA 19341
RB
(JP4)
JP4 / JP5 JUMPERS
(1=SHORTED; 0=OPEN)
RA
1
0
0
Revision Level: C
ECO 044952
RA
(JP5)
SELECT
VOLTAGE
OUTPUT RANGE
RB
V = 0-1 volt
out
V = 0-5 volt
out
V = 0-10 volt
out
Revision Date:
May 08, 2018
System Setup
Page
4-18
