Bacharach Fyrite InTech Quick Start Manual

COMBUSTION GAS ANALYZER
QUICK START GUIDE
P/N: 0024-9513
Revision 0
February 23, 2016
This quick start guide provides basic infor-
mation. For safety warnings, additional
instructions, and more detailed informa-
tion, refer to the Configuration and Opera-
tion manual (part number 0024-9486)
available at www.MyBacharach.com.
PREPARE
Review functions and locations of
key components (1 through 20)
Connect the probe (14 to 11, and
15 to 13)
Turn on the instrument (9)
Verify power (1)
Full
Medium
Low
Replace
Wait for warm-up to complete
1 Display with backlight
2 Function keys
3-6 Navigation keys
7 Enter key
8 Escape key
9 Power/backlight key
10 Run/hold key
11 T-Stack port
12 USB port
13 Sample gas port
14 Sample gas
thermocouple (T-Stack)
connector
15 Sample gas hose
16 USB cable (Optional)
17 Location of optional
NOx filter
18 Water trap and
filter assembly
19 Probe handle
20 Probe tube
CONFIGURE
Access and navigate the menus
Select fuel type
Use default configuration values or
navigate to Setup Menu to set
combustion test parameters
BOTTOM
VIEW
MAINTAIN
Replace sensors as needed
Open
Slot
O Cap
2
Nub
O Sensor
2
CO Sensor
Printed Circuit Board
Calibrate as needed
Leave Top
FLOW METER
Port Open
T-STACK
USB
GAS
Replace batteries as needed
Battery
Compartment
Replace water trap (18) filter as
needed
Filter
CO
Cap
