Appendix A – Spare Parts List
5.1
PART NUMBER
C1-11-1220-03-0
8-01-1000-02-2
6-01-1001-91-0
C1-16-1000-01-1
5-06-4900-53-0
C6-01-1000-02-0
6-01-1000-17-0
C6-01-1000-13-0
C6-01-1000-12-0
C6-01-1000-11-0
C1-08-0000-00-0
C1-17-0052-00-0
C1-17-0142-00-0
C1-17-0112-00-0
1-17-1052-00-0
5 – A
PPENDICES
Vac Fuses for Power Supply Board (for Vac units only). – 1A,
250Vac, Slo-Blo
Oxygen Sensor Model GP: 0-25%
Oxygen Sensor Model IT: 0-25%
Oxygen Sensor Model CAG-250N: 0-100%
Operations Manual
Vac Power supply (for Vac units only)
12/24 Vdc Power Supply (for Vdc units only)
Relay Board
Main CPU Board
Display Board
Front Panel
Replacement terminal block – TB1
Replacement terminal block – TB2
Replacement terminal block – TB3
Replacement terminal block – TB4
DESCRIPTION
