2.2

Starting up and Commissioning the System

Figure 10 – start-up
outline
The Model Mini-ICS is shipped ready to use, right from the carton. Factory default configuration
settings are listed in Appendix C for your information. Those settings will be suitable for most
applications. Review the factory default configuration settings before commissioning your system.
If you wish to change any of the factory default settings, refer to sections 4.1.1 and 4.1.2.
POWER UP CHECK LIST
Have you:
Mounted the analyzer and sensor in an area where there are no flammable vapors?
Mounted the analyzer and sensor away from exposure to rain, dripping water, or hose down?
Correctly installed the sensor/sampling system?
Correctly installed all of the analyzer wiring (Including barrier interfaces where required)?
Read this manual in its entirety?
2.2.1 STEP 1 – Power Up the unit
When the Model Mini-ICS is powered-up, it will go through a 5-second self-test. The 7-segment
alphanumeric display will show "8.8.8.8.", then XXXX (software version). The Normal, O
Low Flow, and Fault LED indicators will go through a display test sequence (Lamp Test).
Following self-test, the analyzer will enter into one of its RUN modes (section 3.3). The analyzer
will check its input reading and update the 7-segment alphanumeric display and status LED's
accordingly. Though the unit can be immediately used after self-test, best stabilization of the
sensor signal may be obtained after the instrument has been on for approximately 20 minutes.
This will allow the sensor to stabilize and adjust to the ambient temperature.
Manual Part Number:
5-06-4900-53-0
Starting up and Commissioning the System
STEP 1:
POWER UP
STEP 2:
INITIAL CALIBRATION
STEP 3:
SET OXYGEN ALARM &
INERT GAS CONTROL
LIMITS
Revision Level: C
ECO 044952
Revision Date:
May 08, 2018
Alarm,
2
Page
2-11
