ITech IT-M3600 Series User Manual page 20

No. Name
5 Output status
6 The indication for
current direction
Under load mode:
No. Name
1 Output Voltage
2 Output Current
3 Output Power
4 Voltage setting
value
5 Output status
Copyright © Itech Electronic Co., Ltd.
Description
•
OFF: Output is disabled.
•
Displays the present output status when the
output is enabled.
Indicates present current setting value is positive
current limit.
The indication displays only in CV priority
mode.
Description
Displays the present output voltage value.
Displays the present output current value.
Displays the present output power.
Displays the present voltage setting value. In this
area, displays setting value according to present
mode and is different under different mode.
•
OFF: Output is disabled.
•
Displays the present output status when the
output is enabled.
Quick Reference
8
