During testing, if there is no SDS module, the alert box will appear with "No SDS
Module Detected, Continue? No/Yes'',after select "Yes", the testing will be
continued. As long as any one of the cut-off conditions is met, the test stops.
Stop running and re-running
During the running of battery test file, press [Shift]+[I-set](Function) composite
key, and the instrument interface displays the running state control interface of
the existing file. The user can press Stop to stop existing test and turn off the
List function. Or, press Reset to restart a new test.

4.2.3 Battery emulation function

When the instrument is under the source mode, the user can emulate the bat-
tery charge and discharge properties due to the unique current bipolarity design
and variable output impedance. In the battery emulation function, the instrument
can emulate the scenes where several batteries are in parallel connection/serial
connection, and set the initial state of charge of the battery based on needs for
true emulation of various states of the battery to meet various test requirements
of the user.
During the emulation of charge and discharge test functions of the battery, the
user needs to set battery-related attributes, such as full-state voltage value,
empty-state voltage value, internal resistance value and capacity. Set the paral-
lel connection and serial connection for emulation batteries, as well as the posi-
tive and negative current limits of the battery group.
Batt Battery emulation test function
Emula-
tor
Run
Recall
Run battery emulation function
Initial SOC Set the initial state of charge of battery
Recall the battery emulation file to be run
Recall File=1/ Select the number of file to be recalled. The total number
10 of files is 10. When the selected file does not exist, the in-
strument would prompt that the file is empty.
Cell
Properties
Copyright © Itech Electronic Co., Ltd.
Power Supply Function
During Recall, the user can only view
the battery attribute, and cannot edit it.
Full Volt: Battery voltage value under full
state
Empty Volt: Battery voltage value under
empty state
Inner R: Battery internal resistance
value
Capacity: Battery capacity
