Pin Name
9 Power
10 CC
11 ALM
13, 25 RS485–A,
RS485–B
14 Vol_MON
15 Cur_Pro
16 Cur_MON
Copyright © Itech Electronic Co., Ltd.
Type Description
input, the instrument state is switched
to On.
Digital Indicate the instrument's loading state:
output Under normal loading state, 5V is out-
put; under non-loading state, 0V is
output.
Digital Indicate the instrument's working
output state: Under the CC mode, 5V is out-
put; otherwise, 0V is output.
Digital Indicate the instrument's fault state: If
output the instrument is normal, 5V is output;
if the instrument is abnormal, 0V is
output.
Commu- RS485 interface connection terminal.
nication
terminal
Analog Monitor the voltage, and output 0 ~
output 10V voltage value to monitor the DC
terminal voltage between 0 and full
scale.
Analog Under the source mode, set current.
input The input range varies under different
modes.
•
When CV is prioritized, input 0 ~
10V voltage value to set the nega-
tive current limit (I_Lim- value) be-
tween 0 and negative full scale;
•
When CC is prioritized, input –10V
~ 10V voltage value to set the cur-
rent value between negative full
range and positive full scale;
Analog Monitor current. The output range
output varies under different modes.
•
Under the source mode, output –
10V ~ 10V voltage value to monitor
the output or absorption current be-
tween negative full range and posi-
tive full scale;
System-Related Functions
