INTRODUCTION

GENERAL INFORMATION

This VEHICLE SHOP MANUAL covers the following BRP made SEA-DOO
should be used in conjunction with the 717/787 RFI ENGINE SHOP MANUAL.
MODEL
3D
3D Premium
3D Premium
GTI
GTI RFI
GTI RFI LE
The use of RIGHT (starboard) and LEFT (port) indi-
cations in the text, always refers to driving position
(when sitting on watercraft).
Besides, in the marine industry, FRONT is called
BOW and REAR is called STERN.
1
F01L45B
1. Left (port)
2. Right (starboard)
The information and component/system descrip-
tions contained in this manual are correct at time
of writing. BRP however, maintains a policy of
continuous improvement of its products without
imposing upon itself any obligation to install them
on products previously manufactured.
BRP reserves the right at any time to discontinue
or change specifications, designs, features, mod-
els or equipment without incurring obligation.
smr2005-041
COLOR
Yellow
Red
Yellow
Yellow
Yellow
Yellow
2
www.SeaDooManuals.net
® 2005 watercraft models. It
ENGINE TYPE
787 RFI
787 RFI
787 RFI
717
787 RFI
787 RFI
CAUTION: These watercraft are designed with
parts dimensioned mostly in the metric sys-
tem. However some components may be from
the imperial system. When replacing fasten-
ers, make sure to use only those recommended
by BRP.
This VEHICLE SHOP MANUAL uses technical
terms which may be slightly different from the
ones used in the Parts Catalog.
When ordering parts always refer to the specific
model PARTS CATALOGS.
Hull Identification Number (H.I.N.)
The Hull Identification Number is composed of 12
digits:
smr05-002-001_aen
INTRODUCTION
MODEL NUMBER
195A, 195B
205E, 205F
205A, 205B
105A, 105B
125A, 125B
135A, 135B
IX
