Power Save Modes

The PVS 407D is an ENERGY STAR
(see the table below for mode descriptions and
Mode Type Activation
0 Normal None
1 Auto Timed after setup.
Power If no audio and
Save video signal (from
inputs 1 to 6) or
audio signal (from
switchable program
inputs, Aux input,
and VoiceLift input)
is detected for
25 consecutive
minutes, mode 2 is
enabled.
2 Forced Instant
Auto
Power
Save
3 Forced Instant
Standby
Power
Save
4 Forced Instant
Network
Standby
Power
Save
NOTE: Front USB and rear remote RS-232 ports are powered and active all the time regardless of the
current power save mode.
qualified device, and has five Power Save modes,
®
Device and
System power
Fully powered. Status
LED is green.
Amplifier and rest of
system is powered until
mode 2 is entered. The
Status LED is green in
mode 1.
Amplifier is off. Rest of
system is powered. The
Status LED is amber.
Amplifier is off. Wallplates
off. VLR 102 receiver off.
Rest of system is powered.
Status LED is amber.
On PVS 407D, only USB,
RS-232, network switch
ports, and input buttons
are functional.
Amplifier is off. Wallplates
off. VLR 102 receiver off.
Network switch off. Rest
of system is powered.
The Status LED is amber.
On PVS 407D, only
USB, RS-232, and input
buttons are functional.
Power save mode on page 25).
Wake-up trigger
N/A
An active switchable
program audio signal which
is referring to selectable
inputs 1 to 7, or when an
input is switched, or if the
volume is adjusted.
The audio timer is reset.
Can also be woken by SIS
command (resets device to
mode 0).
If entered from mode 1,
can be woken by an active
switchable program audio
signal which is referring to
selectable inputs 1 to 7, or
when an input is switched,
or if the volume is adjusted.
Reverts to mode 1.
If set instantly by SIS
command, can only be
woken by SIS command,
input selection, or volume
adjustment.
Reverts to the previously set
mode (0 or 1).
Pressing the front input
toggle button, or switching
the inputs from the attached
MLC controller.
Reverts to the previously set
mode (0 or 1).
Can also be woken by SIS
command.
Pressing the front input
toggle button, or switching
the inputs from the attached
MLC controller.
Reverts to the previously set
mode (0 or 1).
Can also be woken by SIS
command.
PVS 407D Switcher • Operation
Setup
Command
Default state,
SIS command
reset
By SIS
command or
Configuration
Software
(PCS)
Either from
mode 1 or set
instantly by
SIS command
SIS command
only
SIS command
only
