To configure the settings for use with DHCP:
1. Set the DHCP slider (
2.
Click SAVE (
IT administrator for more information.
Click CANCEL to exit the process without making any changes.
To configure the settings with a static IP address:
1. Ensure the DHCP slider (
2. In the IP Address field (
3. In the Subnet field (
4. In the Gateway field (
5. Click SAVE (
making any changes.
NOTE: The default TCP/IP settings are:
• IP address = 192.168.254.254
• Subnet Mask = 255.255.0.0
• Default Gateway = 0.0.0.0

Audio Stream

The Audio Stream panel (see
settings for the PVS 407D. In this example, the settings are shown after the LinkLicense
is installed. (Refer to
The Audio Stream settings on the PVS 407D default webpage are disabled until the
PVS 407D Audio Decoding LinkLicense is applied to the switcher. With the LinkLicense
successfully added, audio stream settings are accessible as shown in the figure. IP
address and UDP port settings should be coordinated with your GlobalViewer Campus
Communication Suite and network administrators for proper operation.
To change the settings, click EDIT to access the Audio Stream Settings dialog box
(see figure 31
1. Change the desired criteria or click Reset to default (
settings.
2. Click SAVE (
making any changes.
The settings include:
• IP Multicast Address (
stream on the defined UDP Public or Priority port. Default: 239.255.25.250.
Server IP Address (
•
Communication Suite (GVCCS) server PC. Default is 0.0.0.0.
• UDP Public port (
UDP port to a value between 1024 and 65535. UDP Port numbers 0 to 1023 are
reserved and cannot be assigned. Default is 3030.
UDP Priority port (
•
UDP port to a value between 1024 and 65535. UDP Port numbers 0 to 1023 are
reserved and cannot be assigned. Default is 2020.
) to On.
A
). An IP address is automatically assigned to the device. Contact your
B
) is set to Off.
A
), enter an IP address for the device.
C
), enter the subnet mask for the device.
D
), enter the default gateway to be used.
E
) to apply the changes, or click CANCEL to exit the process without
B
figure 27 on page 47) shows the current audio stream
LinkLicense on page 53 for installation information.)
on the next page).
) to apply the changes, or click CANCEL to exit the process without
B
): Enter a Multicast address on which to receive an audio
C
): Enter the IP address of the GlobalViewer Campus
D
): Enter the port number for receiving a UDP stream. Set
E
): Enter the port number for receiving a priority UDP stream. Set
F
) to return to the factory
A
PVS 407D • Using the Internal Web Page 50
