Connect to a Device

To connect to the device or re-establish the connection:
From the device menu, select Connect.... The Connect dialog box opens.
1.
Figure 22.
Choose the device from the Device Discovery list (TCP/IP or USB connection)
2.
or select the Pass-Thru tab, depending on the desired connection method. For
devices where the IP address is known, but the device is not listed, select the
TCP/IP tab.
NOTE: The factory configured password for all accounts on this device have
been set to the device serial number. Passwords are case sensitive. If the
switcher is reset, the password reverts to the default, which is no password. A
new password would need to be configured to secure the device.
• For a USB or TCP/IP connection, select a listed device (see figure 22).
For a Pass-Thru connection:
•
a.
b.
c.
d.
e.
Connect Dialog Box
Click the Pass-Thru tab. The Pass-Thru panel appears (see
the next page).
Enter the IP address of the connected MLC. When checked, the Show
Characters check box allows the user to see the password letters when
typed in.
If applicable, enter the password of the connected MLC.
Enter the Telnet Port for the connected MLC (default is 23).
Enter the Pass-Thru Port number for the connected MLC (default is 2003).
PVS 407D • Configuration Software
figure 23 on
42
