Final Setup

With an MLC Plus 100 as a standard MLC controller in the PoleVault system package, the
PVS 407D switcher completed setup should look similar to the figure below.
Ensure all connections are correctly made and secure. Use LockIt brackets to secure
HDMI cables (see below).
NOTE: See the PoleVault System Installation Guide and MLC Plus 50/100/200
1/2 3/4
SIG LINK SIG LINK
POWER
12V
3A MAX
PVT IN PVT IN
M A
Power Connector
AUDIO IN AUDIO IN
HDMI IN VGA IN
e
PVT HD RGB
HDMI or RGB video/audio,
Supplied PVS Inputs 1/2 and 3/4,
Switcher External 1 XTP DTP 24 cable with RJ-45 connectors
Power Supply
(12 VDC, 4 A, or
12 VDC, 4.2 A)
Figure 7.

Securing the HDMI Cable

The supplied Extron LockIt HDMI cable lacing bracket makes
it possible to secure a standard HDMI cable to the PVS 407D
switcher.
To securely fasten an HDMI cable to the PVS 407D (see image
at right):
1
2
3
4
5
Series Setup Guide for full MLC installation, configuration, and operating details.
PVS 407D
OUTPUT
INPUTS
5 6
HDMI HDMI
B G
HDMI
HDMI
Connector
Connector
HDMI Input HDMI Output to
Display Device
Sources,
Inputs 5 and 6
NOTES:
• If you use cable that has a drain wire, tie the drain wire
to ground at both ends.
• You must connect a ground wire between the MLC
and PVS.
PVS 407D Connections
Plug the HDMI cable into the rear panel HDMI connector.
Loosen the HDMI connection mounting screw from the
rear panel enough to allow the LockIt lacing bracket to be
placed over it. The screw does not have to be removed.
Place the LockIt lacing bracket on the screw and against
the HDMI cable connector.
Lightly tighten the screw to secure the bracket.
Place the included tie wrap around the HDMI connector
and the LockIt lacing bracket and tighten as shown in the
images at right.
