 The current-carrying capability of the DC bus copper bar of a unit is only 100A or 200A. For details about the
specification, see section 3.6 Product ratings. The current on the DC bus copper bar cannot exceed its
current-carrying capability.
 There are two types of external bus terminals: 100A and 200A. Please select the terminals according to the current
requirements, and note that the current on each terminal cannot exceed its current-carrying capacity.

4.3 Mechanical installation

4.3.1 Installation environment

The installation environment is essential for the VFD to operate with best performance in the long run. Install the VFD in
an environment that meets the following requirements.
Environment
Installation site
Ambient
temperature
Presentation
I
+ -
Rectifier units
II
+ -
Rectifier units
Indoor
 -10–+50° C
 When the temperature exceeds 40° C, derate 1% for every increase of 1° C.
 Do not use the VFD when the ambient temperature exceeds 50° C.
 In order to improve reliability, do not use the VFD in the places where the
temperature changes rapidly.
 When the VFD is used in a closed space, such as control cabinet, use a cooling
fan or air conditioner for cooling, preventing the internal temperature from
exceeding the temperature required.
 When the temperature is too low, if you want to use the VFD that has been idled
I
I I
3
1 2
Inverter units
I I I I
4 5 6 7
...
Inverter units
Condition
-20-
Condition
I + II ≥ 0.8 * (I
1
...
I + I + I + I
3 4 5
+ ...)
I / II ≈
(I + I
1
+...)/ (I
+ I + I
4 5
+ ...)
+... ≤ 200A
I + I + I
1 2 3
+ ...≤
I + I + I + I
4 5 6 7
200A
+ ... ≤100A
I + I + I
5 6 7
+ ...≤100A
I
3
Installation
+ I +
2
+ I
6 7
+ I
2 3
+ I
6 7
