INVT Goodrive600 Series Operation Manual page 48

Goodrive600 series high-performance multifunction VFD
485+
CAN2H
GND
+10V
AI1
COM
CME
COM
COM
PW
+24V
Short-circuit wires of the inverter unit
NPN wiring mode:
Short PW to +24V, and connect the COM terminal of the VFD to the common terminal of the external controller when the
internal 24V power supply of the VFD is used.
Remove the short-circuit wires between the PW and +24V terminals, connect the positive terminal of the external 24V
power supply to the PW terminal, and connect the negative terminal of the external 24V power supply to the S terminal
through the switch of the external controller when an external 24V power supply is used.
PNP wiring mode:
Short-circuit wire for
connecting CME to
COM
485+ 485-
CAN2H CAN2L
GND
CGND
+10V
AO1
AI1 AI2
COM
COM
CME Y1
COM S4
485-
COM S3
CAN2L
CGND S2
PW
AO1
AI2
+24V S1
COM
Y1
S4
S3
S2
S1
Short-circuit wire for
connecting PW to
+24V
Figure 4-14 Diagram of short-circuit wire position
S1
S2
COM
COM
+ 24V
PW
+ 24V
Internal power supply (NPN mode)
Figure 4-15 NPN wiring mode diagram
S1
S2
COM
COM
+ 24V
PW
+ 24V
Internal power supply (PNP mode)
Figure 4-16 PNP wiring mode diagram
CAN1H CAN1L
CAN2H CAN2L
485+ 485-
CGND S5
COM S4
COM S3
PW S2
+24V S1
Short-circuit wires of the rectifier unit
S1
S2
COM
COM
+24V
+ 24V
PW
+ 24V
External power supply (NPN mode)
S1
S2
COM
COM
+ 24V
PW
+ 24V
External power supply (PNP mode)
-40-
CAN1H CAN1L
CAN2H
CAN2L
485+
485-
CGND S5
COM
S4
COM
S3
PW S2
+24V
S1
Short-circuit wire for
connecting PW to
+24V
Installation
