Goodrive600 series high-performance multifunction VFD
Function
code
Number system of
P14.33 control and status words
for communication cards
Enabling the jog mode
P14.35
through local keypad
P14.35–
P14.40
P15 group––Functions of communication card 1 (PROFIBUS-DP)
Function
code
P15.00
P15.01 Module address
P15.02 Received PZD2
P15.03 Received PZD3
P15.04 Received PZD4
P15.05 Received PZD5
P15.06 Received PZD6
P15.07 Received PZD7
P15.08 Received PZD8
P15.09 Received PZD9
P15.10 Received PZD10
P15.11 Received PZD11
P15.12 Received PZD12
Name
2: Coast to stop
3: Decelerate to stop in emergency manner
0: Decimal system
1: Binary system
Note: The rectifier unit and inverter unit must be
the same in the value of the function parameter.
0: Disable
1: Enable
Note: Invalid when a LCD keypad is
connected.
Reserved 0–65535
Name
Reserved 0–65535
0–127
0: Disable
1: Set frequency (0–Fmax (Unit: 0.01Hz))
2: PID reference (0–1000, in which 1000
corresponds to 100.0%)
3: PID feedback (0–1000, in which 1000
corresponds to 100.0%)
4: Torque setting (-3000–+3000, in which 1000
corresponds to 100.0% of the motor rated
current)
5: Setting of the upper limit of forward running
frequency (0–Fmax, unit: 0.01 Hz)
6: Setting of the upper limit of reverse running
frequency (0–Fmax, unit: 0.01 Hz)
7: Upper limit of the electromotive torque (0–
3000, in which 1000 corresponds to 100.0% of
the motor rated current)
8: Upper limit of braking torque (0–2000, in which
1000 corresponds to 100% of the motor rated
current)
9: Virtual input terminal command.
Range:0x000–0x1FF
10: Virtual output terminal command. Range:
0x00–0x0F
11: Voltage setting (special for V/F separation)
(0–1000, in which 1000 corresponds to 100% of
the motor rated voltage)
12: AO1 output setting 1 (-1000–+1000, in which
1000 corresponds to 100.0%)
13: AO2 output setting2 (-1000–1000, in which
Description
Description
-304-
Function parameter list
Default Modify
○
0
○
0
●
0
Default Modify
●
0
◎
2
○
0
