Goodrive600 series high-performance multifunction VFD
Appendix E Optional peripheral accessories
E.1 What this chapter contains
This chapter describes how to select optional accessories of the VFD.
E.2 External wiring
The following figure shows the external wiring of the VFD.
485+
485-
Power
supply
Breaker
Input reactor
Earth
Input filter
Figure E-1 External wiring of the VFD
-399-
Upper PC
software
RS485–
USB
converter
PC
-
+ +
PB
Braking
Braking
resistor
unit
Output filter
Output
reactor
Motor
Earth
Optional peripheral accessories
