INVT Goodrive600 Series Operation Manual page 384

Goodrive600 series high-performance multifunction VFD
Indicator
LED4
A.5.3 Ethernet communication card——EC–TX704
EC-TX704 uses standard RJ45 terminals.
Indicators:
Indicator
LED1
LED4
Definition
Power indicator
LED3 LED2
LED1
LED4
Definition
This indicator is on when the expansion card is establishing a
connection with the control board; it blinks periodically after the
Status
expansion card is properly connected to the control board (the period
indicator
is 1s, on for 0.5s, and off for the other 0.5s); and it is off when the
expansion card is disconnected from the control board.
Power This indicator is on after the control board feeds power to the
indicator communication card.
Function
communication card is different from that during the
network configuration.
It blinks at the frequency of 4 Hz when an error occurs
in the ASIC initialization of PROFIBUS
communication.
It is off when the diagnosis function is disabled.
This indicator is on after the control board feeds power
to the communication card.
Function
-376-
Expansion cards
RJ45
