INVT Goodrive600 Series Operation Manual page 357

Goodrive600 series high-performance multifunction VFD
Inverter fault
code
E-NET
E-CAN
ETH1
ETH2
dEu
STo
LL
ENC1O
Fault type
Ethernet
communication fault
CANopen
communication fault
To-ground short circuit
fault 1
To-ground short circuit
fault 2
Speed deviation fault
Maladjustment fault
Electronic underload
fault
Encoder offline fault
Possible cause
Communication line fault.
Incorrect communication
address.
Communication suffers from
strong interference.
Incorrect baud rate.
Communication line fault.
Incorrect communication
address.
Inverter output is short
connected to the ground;
Current detection circuit is
faulty;
Actual motor power setup
deviates sharply from the
inverter power.
Inverter output is short
connected to the ground;
Current detection circuit is
faulty;
Actual motor power setup
deviates sharply from the
inverter power.
Load is too heavy, or stall
occurred.
Control parameters of the
synchronous motor is set
improperly;
The parameter gained from
autotuning is inaccurate;
The inverter is not
connected to the motor.
The inverter performs the
underload pre-alarm based
on the set value
Encoder line sequence is
wrong, or signal wires are
-349-
Troubleshooting
Solution
to enhance the
anti-interference capacity.
Check the communication
interface cable.
Set the communication
address correctly.
Replace or change the wiring
to enhance the
anti-interference capacity.
Set a proper baud rate.
Check the communication
interface cable.
Set the communication
address correctly.
Replace or change the wiring
to enhance the
anti-interference capacity.
Check whether the
wiring is proper;
Replace the hall component;
Replace the main control
board;
Reset the motor parameters
properly.
Check whether the
wiring is proper;
Replace the hall component;
Replace the main control
board;
Reset the motor parameters
properly.
Check the load to ensure it is
proper, and increase
detection time;
Check whether the control
parameters are set properly.
Check the load to ensure it is
proper,
Check whether the control
parameters are set correctly;
Increase the maladjustment
detection time.
Check the load and overload
pre-alarm threshold
Check the encoder wiring.
motor
motor
the
