INVT Goodrive600 Series Operation Manual page 318

Goodrive600 series high-performance multifunction VFD
Function
code
P17.21
P17.22
P17.23 PID reference value
P17.24 PID feedback value
P17.25 Motor power factor
P17.26 Duration of this run
Present step of simple
P17.27
Motor ASR controller
P17.28
Pole angle of open-loop
P17.29
Phase compensation of
P17.30
P17.31 superposition current of
P17.32 Motor flux linkage
P17.33
P17.34
P17.35 AC incoming current
P17.36
Motor overload count
P17.37
P17.38 Process PID output
Parameter download
P17.39
Name
Reserved 0–65535
Reserved 0–65535
Displays the PID reference value.
Range: -100.0–100.0%
Displays the PID feedback value.
Range: -100.0–100.0%
Displays the power factor of the current motor.
Range: -1.00–1.00
Displays the duration of this run of the inverter
unit.
Range: 0–65535min
Used to display the present step of the simple
PLC PLC function.
Displays the ASR controller output value under
the vector control mode, relative to the
percentage of rated motor torque.
output
Range: -300.0%–300.0% (of the motor rated
current)
Displays the initial identification angle of SM.
SM Range: 0.0–360.0
Displays the phase compensation of SM.
SM Range: -180.0–180.0
High-frequency
0.0%–200.0% (of the motor rated current)
SM
0.0%–200.0%
Displays the exciting current reference value
Exciting current
under the vector control mode.
reference
Range: -3000.0–3000.0A
Displays the torque current reference value
Torque current
under the vector control mode.
reference
Range: -3000.0–3000.0A
Displays the valid value of incoming current on
AC side.
Range: 0.0–5000.0A
Displays the output torque value. During forward
running, the positive value is the motoring state
while the negative value is generating state.
Output torque During reverse running, the positive value is the
generating state while the negative value is the
motoring state.
Range: -3000.0Nm–3000.0Nm
0–65535
value
-100.0%–100.0%
0.00–99.00
error
Description
-310-
Function parameter list
Default Modify
●
0
●
0
●
0.0%
●
0.0%
●
1.00
●
0m
●
0
●
0.0%
●
0.0
●
0.0
●
0.0
●
0.0%
●
0.0A
●
0.0A
●
0.0A
●
0.0Nm
●
0
●
0.00%
●
0.00
