Access Easy Controller
Location
AC Input to Circuit Breaker to Line Filter.
Line Filter to Power Supply
RJ45 to CMC, directly or via hub
Power Supply to CPU Card (T2)
CPU T2 to Reader Boards, Battery and
Tamper Switch*
Reader Board to Reader Board or I/O Card.
Bosch Security Systems
Cable Type
3-conductor, 2.5 sq mm PVC insulated.
3-conductor, 2.5 sq mm PVC insulated.
UTP Category 5 Cable
Belden 9409 - 18AWG, 2-conductor,
unshielded
Belden 9409 - 18AWG, 2-conductor,
unshielded
28AWG, 40-Way Ribbon Cable.
Hardware Manual
APPENDIX C Detail Wiring | en 195
Ver 2.0.0 | 2006.07
