16 en | System Layout
CPU Card
Interface Cards
Cards
Power Required
Number of Wiegand Readers Sup-
ported
Number of Input Monitoring Points 8*
Number of Output Control Relays
* Input Monitoring Points on the 4-reader board consists of door contact input and request-to-
exit inputs associated with reader controlled doors.
** Output Control Relays on the 4-reader board are the door strike/magnetic lock control
relays for the reader-controlled doors.
Operating Environment
Operating Temperature
Humidity
Recommended Web Browsers:
Number of Concurrent Logins:
Software Protection:
Database Integrity:
Number of Cards Supported:
Number of Access Groups:
Number of Time Schedules:
Intervals per Time Schedule:
Ver 2.0.0 | 2006.07
CPU type: 32-bit Microprocessor
Type of Memory: 128 MB RAM, 32 MB Flash
Ports:
a. 1 or 2 Ethernet Port
b. 2 RS-232 Port
c. 1 Parallel Port
Hardware Manual
4-Reader
15VDC (from Power Sup-
ply Card)
4
8**
0 to 50 deg. C
10% to 95% non-condensing
Microsoft Internet Explorer 4.0 and later, Netscape
Navigator 4.0 and later. (Netscape 6.0, 6.1 and 6.2
are not supported)
8
Can create up to 25 individual user accounts, each
with password protection. SAM controls license of
number of user accounts.
Built-in data encryption used for processing of sensi-
tive information such as: user passwords, PINs, etc
20,478
255
255
Four intervals per day, plus holidays support.
Access Easy Controller
8-Input/8-Output
15 VDC(from Power Sup-
ply Card)
-
8
8
