Access Easy Controller
Location
RJ45 to CMC, directly or via hubUTP
Transformer output to CPU Card (T1)
CPU T1 to Reader Boards, Battery and
Tamper Switch*
CPU Card to Reader Board or I/O Card,
Reader Board to Reader Board or I/O
Card.
Bosch Security Systems
Cable Type
Cat. 5 Cable
Belden 9409 - 18AWG, 2-conductor,
unshielded
Belden 9409 - 18AWG, 2-conductor,
unshielded
28AWG, 40-Way Ribbon Cable.
Hardware Manual
APPENDIX C Detail Wiring | en 193
Ver 2.0.0 | 2006.07
