I
NPUTS

Inputs

Minimum ON current
Maximum OFF current
Short Circuit protection( per side)
Sensor port inputs are auto-sensing for the connected circuit type of either PNP or NPN. Please note that both
sourcing and sinking current will activate the input.
Each port utilizes load detection circuits between the +24V (Pin 1) and Gnd (Pin 3). This circuit provides input to
the processor to detect if a power consuming device is connected. Short circuit between Pin 1 and Pin 3 can cause
damage to the load detection circuit and render this function inoperable.
O
UTPUTS

Outputs

Output count
Maximum current ( per Output)
Short-circuit protection threshold( per Output
E S
THERNET PECIFICATION
• 3 port integrated switch ( 2 external ports and 1 port for the on-board processor)
•
Automatic speed setup (10Base-T / 100Base-TX)
•
Automatic duplex configuration (Full / Half)
•
Automatic straight/crossover cable detection ( Auto MDI/MDI-X)
• PAUSE frame support
• Back pressure flow control support
•
Maximum segment length: 100m / 328ft
S
UPPORTED NETWORK PROTOCOLS
•
Modbus/TCP
•
EtherNet/IP
•
Profinet I/O
Appendix A – Module Specifications
•
PNP/NPN Auto-sensing (Default)
•
Up to 8 per module - 2 inputs per port
• Programmable Push-Pull selectable
1.5mA
0.4mA
500mA max
PNP only
Up to 8 per module
300mA
500mA
Publication ERSC-1008 Rev 1.1 – October 2017
