E R S
ASY OLL OFTWARE
I
NTRODUCTION
The EasyRoll Software Configuration Tool is a PC based application that provides the means to configure a
ConveyLinx controlled conveyor system. EasyRoll also provides the ability to change ConveyLinx module default
parameters.
Installing EasyRoll and performing the initial Auto Configuration is described
in the previous section
B F
ASIC EATURES
Some of the basic module parameters that can be modified by EasyRoll are:
•
Graphical view of the current state of each digital input and output
• Configure the module to be Transparent to the flow of ZPA ConveyLinx-Ai2 in a network
• Blink &Wink function used to visually locate an ConveyLinx-Ai2 on the conveyor
EasyRoll has the ability to display the status information for any ConveyLinx module on the network's subnet.
A F
DVANCED EATURES
Some of the advanced features available with EasyRoll are:
Firmware Upgrade utility for one or a group of ConveyLinx modules
•
• Network Services Discover utility used to find all ConveyLinx modules on a network and manually set their
I.P. addresses.
• Module Connection mapping to logically link two or more separate ConveyLinx networks.
• The ability to Back-Up and Restore the Network Configuration.
• The ability to restore a backup by IP or by Nodes. Restoring by IP's is useful when you need to duplicate
part or all of a system.
•
Access to the Module Auto-Configuration function
•
Access to the Module Replacement function
C T
ONFIGURATION OOL

EasyRoll Software Configuration Tool

Publication ERSC-1008 Rev 1.1 – October 2017
39
