C L IO C
ONVEY INX ONFIGURATION
The configuration data is sent from the controller to the module upon initial connection in order to set optional
module operational parameters.
R C L
EGISTER HART EGEND
M: 4:1502
E: I.Data[2]
C A
ONFIGURATION SSEMBLY
This chart shows the data sent to the PLC from the module when connected. All registers in the module are 16-bit
integer data type.
Register Name / Assembled Address
Module Address
Input/Output M: 4:13800
4:0497 E: C.Data[0]
Input Polarity M: 4:13801
4:0034 E: I.Data[1]
D
ATA
Indicates Modbus TCP Addressing Notation
Indicates Ethernet I/P Addressing Notation
for PLC
Input/Output Configuration
1 = set Pin as Output
0 = set Pin as Input
bit 0 : Left Male Pin2
bit 1 : Left Female Pin2
bit 2 : Right Male Pin2
bit 3 : Right Female Pin2
bit 4 : Left Male Pin4
bit 5 : Left Female Pin4
bit 6 : Right Male Pin4
bit 7 : Right Female Pin4
bit 8 to bit 15 - reserved
Inputs Polarity Configuration
0 = Input signal and logic states equal
1 = Invert logic from signal state
bit 0 : Left Male Pin2
bit 1 : Left Female Pin2
bit 2 : Right Male Pin2
bit 3 : Right Female Pin2
bit 4 : Left Male Pin4
bit 5 : Left Female Pin4
bit 6 : Right Male Pin4
bit 7 : Right Female Pin4
bit 8 to bit 15 - reserved
See Note ①
Connecting to a Remote PLC Controller
Description
Publication ERSC-1008 Rev 1.1 – October 2017
59
