ConveyLinx-IO User's Guide
H C
ARDWARE ONNECTIONS
L R M
EFT AND IGHT ALE
Both of these ports utilize a 4-pin M8 male receptacle. Each receptacle is mechanically keyed to assure proper
orientation upon plugging in. Each of the two signal pins can be configured as a digital input or output.
Input Signal Wiring for Male Port
Publication ERSC-1008 Rev 1.1 – October 2017
I/O P
ORTS
FIGURE 3 - M8 MALE RECEPTACLE AND FEMALE M8 CONNECTOR
Output Signal Wiring for Male Port
