S I
TATUS NDICATORS
ConveyLinx-IO module status is indicated by several LED's. All LED's with the exception of the Ethernet Link and
Activity LEDs are multi-coloured and context sensitive. The following chart indicates the various meanings of all
ConveyLinx-IO LED indicators. Please refer to Figure 2 on page 15 for the item number locations on the module.
By definition Blinking is approximately ½ second on/off cycle and Flashing is approximately ¼ second on/off cycle.
C
OMMUNICATIONS
Indicator
Ethernet Left Link &
Ethernet Right Link
N & M F
ETWORK ODULE
Indicator
Module Status
I
NPUTS
Indicator
Left & Right IO LEDs 2, 3, 4 & 5
O
UTPUTS
Indicator
Left & Right IO LEDs
Item LED State
OFF
On the RJ-45
connectors Solid Green
(13&14)
Blinking Green
UNCTION
Item LED State
Blinking Red
Blinking Green
Flashing Green &
Blinking Red
6
Flashing Red
Blinking Amber
Solid Amber
Item LED State
OFF
Solid Green
Solid Red
Item LED State
OFF
2 & 3 & 4
Flash Green
& 5
Flash Red
Description
No connection established
Connection is established
When data transmission activity is occurring
Description
ConveyLinx-IO is starting task processes
ConveyLinx-IO is ready
Failsafe Mode
Auto Configure Mode is active
Connection to peer lost or performing firmware
upgrade check
Firmware upgrade in progress
Description
Inputs are OFF
Input pin4 is ON
Input pin2 is ON
Description
Outputs are OFF
Output pin4 is ON
Output pin2 is ON
Publication ERSC-1008 Rev 1.1 – October 2017

Status Indicators

23
