1.

PRODUCT OVERVIEW

The B-660-EXT-444-100A is a 4K HDR HDBaseT extender that supports 4K@60Hz 4:4:4 8bit
including DCI 4K (4096 x 2160), and HDCP 2.2 compatibility. It can transmit 1080P signals up
to 100m/330ft and 4K@60Hz signals up to 70m/230ft via Cat 5e/6 cable, and transmit 1080P
and 4K@60Hz 4:4:4 8bit signals up to 100m/330ft via Cat 6a/7 cable.
The B-660-EXT-444-100A supports bi-directional IR pass through, CEC pass through, RS-232
pass through, and ethernet pass-through. With bi-directional PoC support, only one power
adapter is needed. The extender also supports HDMI IN audio de-embedding (analog and
digital) on the 3.5mm analog and Toslink audio output ports.
Two independent 4-pin Video and Audio EDID DIP Switches provide a variety of EDID
combinations to fit the needs of the installation and operation environment. The 4-pin Function
DIP Switches provide a variety of configurations and upgrading requirements to fit multiple
application scenarios.
2.

FEATURES

• Supports resolutions up to 4K@60Hz 4:4:4 8bit and HDCP 2.2.
• Supports HDR (High Dynamic Range), including HDR 10, HLG up to 4K@60 and HDR 10+,
and Dolby Vision up to 4K@30Hz.
• Supports digital and analog audio de-embedding.
• Over a Cat 5e/6 cable, HDBT transmits 4K@60Hz 4:4:4 8bit up to 70m/230ft, and 1080P up
to 100m/330ft; Over a Cat 6a/7 cable, HDBT transmits 4K@60Hz 4:4:4 8bit and 1080P up
to 100m/330ft.
• DIP Switches to configure EDID, IR, RS-232 functions and FW update.
• CEC pass through capable.
• Supports bi-directional IR pass through, RS-232 pass through, and Ethernet pass through.
• Bi-directional PoC, one power adapter at either transmitter or receiver side can power both
units.
3.

PACKAGE CONTENTS

• 1 x B-660-EXT-444-100A Extender
• 1 x DC 12V Power Adapter with US Pins
• 4 x Mounting Ears (with Screws)
• 4 x Drywall Screws
• 8 x Rubber Feet
• 1 x Installation Manual
